Weihai Systems -- 2.4GHz Grid Antenna 12dBi

GR-2412 2.4GHz Grid Antenna 12dBi

2.4G Directional Antenna for Transmitter or Receiver

The GR-2412 Panel Antenna is a 12 dBi directional wireless antenna for the 2.4 GHz band.

Suitable for A/V wireless transmitter/receiver (TR-2020,TR-1020,TR-1020B,TR-500,TR-100,WS-240 )
Support 2.4 GHz wireless AP, wireless router
High Gain 12 dBi to get excellent quality
Extension cable with different connectors to match any wireless device
Easy Installation

Model	GR-2412
Type	Grid Antenna
Frequency	2.4~2.5 GHz
Gain	12 dBi
Connector	SMA Female
Beam Width H	9.5 degrees
Wave Impedance	50 ohm +/- 5 ohm
Dimension	275mm(L) x 125mm(W) x 90mm(H)
Weight	200g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
