TR-1050DK 2.4G outdoor wireless kit

Weatherproof enclosure with high gain antenna for outdoor wireless transmission

This wireless video transceiver is specially designed for outdoor wireless CCTV installation. Built-in high gain antenna with all-in-one compact weatherproof enclosure, providing excellent video quality transmitted without any delay. Suitable for parking lot, playground, swimming pool, ranch, farm, ...... etc.


  • Worldwide NTSC/PAL system applicable

  • High resolution video transmission

  • Long distance transmission

  • Real time video & audio

  • Easy to install and operate

  • Weatherproof

  • High gain antenna

ModelTR-1050DK
Power OutputHigh Power 1W
Frequency Range2400~2483MHz
Channel30-Channel Selectable
Display ModeDigital LED Channel Display
Video-Audio Modulation/Demodulation TypeFM-FM
Antenna12dBi Panel antenna
Transmitter
Power Supply DC 9 ~ 12 V / 320mA
Dimension250mm(L) x 185mm(W) x 60mm(H)
Weight530g
Receiver
Power Supply DC 9 V / 170mA
Dimension250mm(L) x 185mm(W) x 60mm(H)
Weight510g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
