CPS-200AHD 2CH long-distance transmission

Anti-noise and avoid interference

CPS-200AHD is a long distance transmission unit for one CCTV camera. It provides excellent quality in against-noise and good isolation to maintain high performance of video.


  • One pair send 2 AHD video signals for long distance transmission

  • Excellent transmission without interference

  • Easy installation

  • Saving much cost of cable, labor and time

ModelCPS-200AHD
Channels2 Channels
Video ResolutionAHD-H 1080P / AHD-M 720P / 960H / CVBS
Temperature Range-10°C~60°C
Transmitter
Video Input1.0Vp-p (75 ohm)
Power LEDGreen LED
Power Consumption2.1 W
Power RequirementsDC9~12V / 170mA
Dimension102mm(L) x 110mm(W) x 30mm(H)
Weight275g
Receiver
Video Output1.0Vp-p +/- 0.2Vp-p (75 ohm)
Power LEDGreen LED
Power Requirements1.6 W
Power ConsumptionDC9~12V / 130mA
Dimension102mm(L) x 110mm(W) x 30mm(H)
Weight270g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
