TR-1020 2.4GHz Wireless AV Sender

Long distance video transmission with Excellent Penetration

Long Distance model of 2.4GHz audio/video sender. Transmit crystal & clear video and stereo audio signal from CCTV camera / satellite TV / digital TV set top box / DVD player. Available for any AV device and keeping it without interference from other 2.4GHz band. With external & directional dipole antennas to provide an excellent transmission up to 1000 meters (clear line of sight). For longer distance, you can change to optional & powerful Antennas. Unique Frequency to avoid Interference from other 2.4GHz Band.

10-Channel Selectable Antenna Replaceable Easy Installation for CCTV System Transmit any Audio/ Video signal Compatible with both NTSC/ PAL Unique Frequencies to Avoid Interference from other 2.4GHz Band Standard Output / High Power Output Made in Taiwan

Model	TR-1020
Power Output	Standard 10mW / High Power 1W
Frequency Range	2400~2483MHz
Channel Selection	PLL, Synthesizer, 10CH
Video-Audio Modulation/Demodulation Type	FM-FM
Antenna Type	SMA (F)
Power Supply	Tx: DC 12 V / 1 A Rx: DC 9 V / 300mA
Dimension	118mm(L) x 78mm(W) x 32mm(H)
Weight	253g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
