SP-5000 Switch Power Supply

One SP-5000 replaces many adaptors to simplify the power supply

One SP-5000 provides DC-12V, 4A to replace many adaptors for devices. This central power supply is suitable to supply for all DC-12V required devices such as RF-1000, MD-500, DM-100S and VB-104 series.


  • One SP-5000 is instead of many adaptors.

  • Power supply in series connection making installation easy and convenient.

  • Some cameras, modulators or demotulators can be supplied by one SP-5000

ModelSP-5000
Input VoltageAC100 ~230 V
Output VoltageDC12V
Output Current4A
System ProtectionOverloading, Shortage, Temperature
Output / Input 1 Input 8 Output
Dimension155mm(L) x 118mm(W) x 32mm(H)
Weight720g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
