Weihai Systems -- E-Vizion 316 Series

EV-316 E-Vizion 316 Series

Powerful CCTV system with excellent Internet connecting, iPhone/Android monitoring support

E-Vizion 316 provides you the iPhone/Android mobile surveillance by cellular phones and connect all locations of yours via Internet. 16 cameras on one PC and excellent performance of video conference, we just make your life safe and convenient.

Mobile Surveillance
Wherever you are in the world, connecting your E-Vizion via GPRS network by your cellphone
Live Audio Monitoring
At local or remote, you can hear our E-Vizion audio performance very clear on live
IE Browse 16 Cameras
Just enter IP address or domain name, E-Vizion provides you a powerful Web Browser function
Right key Pop-up Menu
Friendly like WindowsOS, use our right-key function to get a menu to setup easily
Channel Image Preview
Provide camera image preview in channel/camera setup, convenient to adjust
Excellent Video and Audio Transmission Quality
Superior two-way communication performance, Video and audio are synchronous
High Accurate In Motion Detection
Trigger threshold and noise filter adjust by system to reduce the rate of mistake
Remote Connection can be Managed by Group
Build your own remote group, one IP on ICON, there is no limitation by E-Vizion
Smart Backup Function
Remote backup to another server in LAN, make sure your files are safer
Event Alarm
Send E-mail alarm message when event is triggered, you can also change different alarm sounds

Model	E-Vizion 316
Video Input	4 Channels on 1 Card for 4 cameras
Audio Input	1 Audio / 1 Card for Audio Recording
System	NTSC / PAL
Display Speed	30 frames per sec (NTSC) 25 frames per sec (PAL)
Video Recording Speed	30 frames per sec (NTSC) 25 frames per sec (PAL)
Audio Recording Quality	From Telephone (11.025KHz) quality to CD (44.1KHz) quality
Video Compression	Built-in MPEG4, support VCM Encoder (unlimited for extension, such as IndeoxR video, Xvid..etc.), can be chosen for an optimal video quality.
PTZ Control	Support PTZ Camera, intuitively PTZ control interface
Dimension	145mm(L) x 118mm(W) x 15mm(H)
Weight	120g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
