DM-100H Digital TV (DVB-T) Receiver

Free Digital TV System for you

This DVB-T receiver is professional designed for receiving free Digital TV signals. Industry Standard for 24/7 working request,it is suitable for small own-built TV system such as Hotel, School,Apartment, Building and Hospital.


  • Professional designed Module to be installed on standard 19" Rack

  • High stability in receiving Digital TV Signal to satisfy the request of MATV

  • Provide excellent quality to receive Free Digital TV

  • One-Touch to switch channel

  • Made in Taiwan

ModelDM-100H
Display ModeDigital LED Channel Display
RF Input range-6dBm~ -90dBm
Transmission standardDVB-T ( ETS300 744 )
ModulationQPSK, 16-QAM, and 64QAM
Video resolution720 X 576 (PAL)/ 720 X 480 ( NTSC)
OSD languageEnglish/ Traditional Chinese
Auto channel searchYes
Power SupplyDC 9V 400mA
Dimension161mm(L) x 118mm(W) x 32mm(H)
Weight450g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
