WS-240 2.4GHz Wireless Data Transmission

Wireless RS485 Data Transmission for PTZ camera

2.4GHz digital UART data control sender transmits UART485 signals which can control speed dome by connecting to PTZ control panel


  • Smart frequency hopping for 2.4GHz UART transmission

  • Fix baud rate at 2400, 4800, 9600 bps

  • Alarm trigger input for remote sensor / setector

  • Long distance transmission

Operation Frequency Range2400 ~ 2483MHz
Modulation type GFSK
Output power 20dBm
Power Supply DC9~12V 300mA
Operating temperature -10C ~ +60C
Baud rate 2400 / 4800 / 9600 bps
Antenna gain 5dbi
Transmitter
Dimension124mm(L) x 69mm(W) x 30mm(H)
Weight265g
Receiver
Dimension124mm(L) x 69mm(W) x 30mm(H)
Weight265g

Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
