AVM-1499 Lower frequency TV channel Modulator

Specially designed for lower frequency channels

AVM-1499 is a TV channel Modulator specially designed for NTSC TV system on CH14-16 & CH96-99.

Modulate A/V signal to your selected TV channel.
Any analog A/V device is available : DVD player, VCR, Satellite Receiver, CCTV camera.
View video source and regular channels on the same TV.
90 dB signal output powerful enough for long cable runs.
Made in Taiwan

Model	AVM-1499
Display Mode	Digital LED Channel Display
Video Signal	NTSC
Video Input	1.0Vp-p for 87.5% modulation
Audio Input	Pre-emphasis 75us.
RF output Strength	90 +/- 5 dbuv
Channel Memory	Last channel memory
Connector	Audio input / Video input (RCA connector), RF out (F connector)
Power Requirement	DC7.5V - DC12V/100mA
Dimension	115mm(L) x 76mm(W) x 31mm(H)
Weight	172g
Remark: The picture & specification shown is tested & provided by RD Team. Any information is subject to be changed without notice.
